Your Heat Sink Solution
Air cooling, water cooling from design to production with thermal simulation service
Air cooling, water cooling from design to production with thermal simulation service
| NO. | Width(mm) | Height(mm) | Weight(kg/m) | Preview | Notes |
| WD-02305 | 298.000 | 47.500 | 8.750 |  |
|
| WD-02306 | 299.000 | 39.500 | 6.950 |  |
|
| WD-02307 | 300.000 | 16.000 | 11.800 |  |
|
| WD-02308 | 300.000 | 49.000 | 7.450 |  |
|
| WD-02309 | 300.000 | 50.000 | 8.320 |  |
|
| WD-02310 | 300.000 | 86.000 | 11.150 |  |
